TEXTDOL 3341 Set-Top Box / TV IC Flash Programming 1.8V Adapter

TEXTDOL 3341 Set-Top Box / TV IC Flash Programming 1.8V Adapter

The TEXTDOL 3341 1.8V Adapter is used for programming low-voltage SPI Flash ICs that operate at 1.8V.

Most standard programmers work at 3.3V, so 1.8V Flash ICs cannot be connected directly. This adapter converts the programmer voltage from 3.3V to 1.8V and helps you safely read, write, erase and program compatible 1.8V memory chips.

It is useful for repairing and programming Flash ICs used in Set-Top Boxes, LED/LCD TVs, computer motherboards, laptops and other electronic devices.

Main Features

• Converts 3.3V programmer voltage to 1.8V
• Suitable for many 1.8V SPI Flash ICs
• Useful for Set-Top Box and TV motherboard repair
• Supports reading, writing and flashing compatible BIOS and Flash memory chips
• Easy to use with supported IC programmers
• Suitable for technicians, repair centres and electronics professionals

Compatible Winbond ICs

W25Q10EW, W25Q20EW, W25Q20BW, W25Q40EW, W25Q40BW, W25Q80EW, W25Q80BW, W25Q16DW, W25Q16FW, W25Q32DW, W25Q32FW, W25Q64DW, W25Q64FW, W25F128FW and other compatible 1.8V models.

Compatible Macronix ICs

MX25U5121E, MX25R512F, MX25U1001E, MX25R1035F, MX25U2033E, MX25R2035F, MX25U4035, MX25U4033E, MX25U4032E, MX25R4035F, MX25U8035, MX25U8035E, MX25U8033E, MX25U8032E, MX25R8035F, MX25U1635E, MX25V1635F, MX25U1635F, MX25R1635F, MX25U3235E, MX25U3235F, MX25R3235F, MX25U6473F, MX25U6435F, MX25R6435F, MX25U12873F, MX25U12835F, MX25U25635F, MX25U51245G, MX25UM51245G, MX66U51235F and other compatible 1.8V Flash ICs.

Important Note

Please check the IC voltage and programmer compatibility before use. Do not connect a 1.8V Flash IC directly to a 3.3V programmer without a proper voltage adapter.

Package Includes:
1 x TEXTDOL 3341 1.8V Flash Programming Adapter
